Waterproof High Density PVC Foam Board Sheet for Kitchen Cabinets

Brand: Aibo

Model No.: GJMS-12

Prouction Technology: Co-extrusion

Standard Size: 1220x2440mm (4'x8')

Thickness: 12.0 mm

Density: 0.60 g/cm3

Color: white faces + yellow core

Packing:  In PE bag /Carton / Pallet

MOQ: 1*20'HQ

Payment Terms:  T/T (30% deposit in advance, 70% balance before shipment);  L/C

Shipment Time: 15-20 days or negotiable

Specification

What is high density pvc foam board?

High density pvc foam board is a new type of environmentally friendly plastic material that replaces wood by using PVC co-extruded foam board. Its main materials are PVC resin and additives, which are foamed and co-extruded.

High density pvc foam board is used as a substitute for wood and plywood without skin. It is easy to use, weatherproof and provides good insulation properties. It also has excellent fire resistance.

At the same time, the high-density pvc foam board has a fixed and amazing moisture resistance; it will not rot, mold or mold. It is also compatible with most resins and adhesives. This high density pvc foam board has excellent fastener pull-out strength and high bending strength and rigidity. It also has strong resistance to chemicals and temperature changes.


Specification

Thickness

3-20mm

Density

0.50 ~ 1.0 g/cm3

Size

1220X2440mm (4' X 8');   Custom size is available

Standard Color

Wood colour( Yellow) in foam core + White on two front surfaces

Surface:

Smooth, Rigid / Surface lamination available


Features:

1. Light weight, waterproof, flame retardant, mothproof, heat preservation, heat insulation and sound insulation.

2. Environmentally friendly and recyclable, it is an ideal substitute for wood, aluminum and composite boards.

3. The surface is smooth, the hardness is high, the impact strength is high, it is not easy to be scratched, and the color can be maintained for a long time.

4. It is easy to assemble, easy to clean and maintain, and is often used in the production of cabinets and furniture.


Processing Options

Cut, Saw, Shear, Punch, Drill, Nail, Mill, Rivet, Screw, Paint, Print, Rout, Heat Bend& Form

Application

1.Furniture board, Wall panel

2.Advertisement, Billboard, Printing board

3.Signage, Sign board, UV Printing

4.Bus Inner Decoration

5.Cupboard (kitchen), Cabinet board

6.Construction (Wall panels, ceilings, decoration etc)

7.Decoration board, Upholstery for train, car.

Application of high density pvc foam board Application of high density pvc foam board WPC Co-extruded Foam Sheet Application of high density pvc foam board


Product Range

Size (Width * Length)

Thickness (mm)

Density( g/cm3)

4' x 8'

3

0.75

4' x 8'

4

0.75

4' x 8'

5

0.75

4' x 8'

6

0.75

4' x 8'

8

0.60

4' x 8'

9

0.60

4' x 8'

10

0.60

4' x 8'

12

0.60

4' x 8'

15

0.60

4' x 8'

17

0.60

4' x 8'

18

0.60

Color

Co-extruded in White+Yellow+White


Note

Custom size is available upon request
